Installation and Programming Manual
3-64
REPORT CODES: ZONES
Quick Key Item Default Explanation
6 2 ZONES
---
used to report the codes generated when an alarm
(or alarm restoral) is sent due to the violation of an
armed zone
6 2 1 Alarm --- press [ENTER] to:
enter the 2-digit zone number and the corresponding
2-digit reporting code used to represent an alarm on
the designated zone
if this event is not to be transmitted, use the “00”
default
press [ENTER] to continue, or press the [.] key to
return to the previous programming level
00 code used to represent an alarm on the designated
zone
6 2 2 Alarm Restore --- press [ENTER] to:
00 code used to represent an alarm restoral on
the designated zone
6 2 3 Trouble press [ENTER] to:
00 code used to represent a Day Zone violation during
the disarmed period
AND/OR
a wireless zone trouble caused by a supervision
failure
6 2 4 Trouble Restore/
Supervision
press [ENTER] to:
00 code for each zone-generated trouble (as described
above) restoral
6 2 5 Bypass press [ENTER] to:
00 code used to represent the selective bypassing (or
force arming) of one (or more) zones
6 2 6 Tamper --- press [ENTER] to:
00 code used to represent a tamper condition resulting
from a violation of a tamper switch on a DEOL
resistor zone
note that even if the zone is bypassed–for which such
a tamper switch is a component–both the tamper
switch and the reporting code will be unaffected
6 2 7 Tamper Restore --- press [ENTER] to:
00 code used to represent the restoral-to-normal of a
tamper condition resulting from the violation of a
tamper switch on a DEOL resistor zone
6 2 8 Low Battery --- press [ENTER] to:
00 code used to represent a low battery condition in the
affected wireless transmitter
6 2 9 Low Battery Restore --- press [ENTER] to:
00 code used to represent the correction of the low
battery condition in the affected wireless transmitter
INSTALLER PROG:
6)REPORT CODES ↓
