Installation and Programming Manual 3-67
REPORT CODES: MAIN (BOARD) TROUBLE
Quick Key Item Default Explanation
6 4
MAIN (BOARD)
TROUBLE
---
• used to report the codes generated when the
following series of troubles related to the Main
Board’s (system) operation is detected
(or restored)
• press [ENTER] to begin
6 4 1 Troubles ---
addresses the trouble codes assigned to the
Pro-24’s Main Board; press [ENTER]
6 4 1 1 Low Battery 00
report code used to represent the detection of a weak
(or missing) standby battery wired to the Main Panel
6 4 1 2
Bell 00
report code used to represent a trouble condition
involving the supervision of an external sounder wired
to the Main Panel
6 4 1 3 Phone 00
report code used to represent a trouble condition
related to the supervision of the telephone service
supplied to the Pro-24
6 4 1 4
AC Loss 00
report code used to represent a trouble condition
related to the AC Power supplied to the Pro-24
6 4 1 5
AUX Fail 00
report code used to represent a trouble condition
related to the loss of Auxiliary Power (either
continuous or switched) supplied by the Pro-24
6 4 1 6 Clock Not Set 00
report code used to represent a trouble condition
caused by a “Clock Not Set”
6 4 1 7 BUS Fail 00
report code used to represent a trouble condition
related to a failure in the system’s 4-wire BUS
6 4 1 8 False Code 00
report code used to represent the repeated use of an
incorrect User Code to disarm the system
6 4 2 Trouble Restorals ---
addresses the trouble restoral codes assigned to the
Pro-24’s Main Board; press [ENTER]
6 4 2 1 Low Battery 00
report code used to represent the restoral-to-normal
of a weak (or missing) standby battery wired to the
Main Panel
6 4 2 2 Bell 00
report code used to represent the restoral-to-normal
of a supervisory condition involving an external
sounder wired to the Main Board
6 4 2 3 Phone 00
report code used to represent the restoral-to-normal
of a supervisory condition involving the telephone
service supplied to the Pro-24
6 4 2 4 AC 00
report code used to represent a restoral-to-normal of
the AC Power supplied to the Pro-24
6 4 2 5 AUX 00
report code used to represent a restoral-to-normal of
the Auxiliary Power (either continuous or switched)
supplied by the Pro-24
6 4 2 6 Clock Is Set 00
enter the 2-digit report code used to represent the
correction of a condition in which the system’s clock
was not set
6 4 2 7 BUS Comm 00
report code used to represent a restoral-to-normal of
the system’s 4-wire BUS
6 4 2 8 False Code 00
report code used to represent the viewing (by the
User within the View Trouble menu–see the Pro-24
User’s Manual) for additional information
