FasTrax™ Inverter Program Instructions
When in Status mode, pressing and holding the “M” MODE key for 2 seconds will change the display from displaying a speed indication to
displaying load indication and visa versa.
Pressing and releasing the “M” MODE key will change the display from status mode to parameter view mode. In parameter view mode, the left
hand display flashes the parameter number and the right hand display shows the value of that parameter.
Pressing and releasing the “M” MODE key again will change the display from parameter view mode to parameter edit mode. In parameter edit
mode, the right hand display flashes the value in the parameter being shown in the left hand display.
Pressing the “M” MODE key in parameter edit mode will return the drive to the parameter view mode. If the “M” MODE key is pressed again then
the drive will return to status mode, but if either of the “UP” or “DOWN” keys are pressed to change the parameter being viewed before the “M”
MODE key is pressed, pressing the “M” MODE key will change the display to the parameter edit mode again. This allows the user to very easily
change between parameter view and edit modes whilst commissioning the drive.
"WARNING: Consult factory before changing any parameters not listed in this table."
Parameter Number Name Default Value New Value Units
00.03 Acceleration Rate 1 5.0 0.5 s/100 Hz
00.04 Deceleration Rate 1 10.0 1.0 S/100 Hz
00.10 Security Status L1 L2
00.18 Preset Speed 1 0.00 0.00 Hz
00.61 Torque Detection Level 0 50 %
FasTrax - Status Modes
Left Display Status Explanation
rd Drive ready The drive is enabled and ready for a start command. The output bridge is inactive.
ih Drive inhibited The drive is inhibited because there is no enable command, or a coast to stop is in
progress or the drive is inhibited during a trip reset.
Er Drive has tripped The drive has tripped. The trip code will display in the right hand display.
dC Injection braking DC injection braking current is being applied to the motor.
Fr Drive output frequency in Hz
SP Motor speed in RPM
Ld Load current as a % of motor rated load current
A Drive output current per phase in A
