PUB. NO. FASTRAXC FEBRUARY 2008 25
FASTRAX
i-COMM LOGIC CONTROLLER
The i-COMM is used to control all functions of the door. Toward
the bottom is a row of green numbered Input (X) LED’s. They
indicate the condition of the door, such as X0 open limit switch,
X1 close limit switch. The column of LEDs toward the right are
called Outputs (Y). Figure 21, Page 11 shows an example of
the i-COMM. Note label inside control box that is a ready
reference to the i-COMM inputs and outputs, Page 12.
DOOR OPERATION AND CONTROLS
1. The door operations are controlled by a Universal
Controller. The controller is set-up and programmed
during testing at the factory. Unless you are a RITE-HITE
DOORS, INC. authorized service technician, you should
not attempt to change the program.
2. A fault will occur if the optional non-powered chain hoist
chain is pulled, simply press the green flashing
"OPEN/RESET" button to return to normal operation.
3. A quick way of determining that the door is ready to
operate, is to open the control box and look at the row of
(X) green Input LED’s on the i-COMM and the label to
verify proper state.
DISCONNECT SWITCH
The red Disconnect Switch stops door operation. The control is
rotated to the "ON" position for normal door operation. To stop
door operation rotate the control to the "OFF" position, Figure 21,
Page 11. Whenever the door operation is stopped by using the
disconnect switch, you must do the following to resume operation.
1. Rotate the red disconnect switch to the "ON" position.
2. Press the "OPEN/RESET" button to reset and open the
door.
GREEN OPEN BUTTON
The green button opens and resets the door after a fault. To
"OPEN", press and release the button. The i-COMM will
automatically close the door after the preset time has expired.
VERIFY DOOR OPERATION
It is recommended that the operation of all controls on the
FasTrax be verified monthly.
Operate the door under normal conditions. Observe the door
opening to make sure that it opens fully. Observe the closing
action to make sure that the door operates smoothly, and fully
closes without excessive curtain ripple at the bottom. The
bottom edge needs to rest completely on the floor for a good
seal, adjust limits as required.
TEST ALL SAFETY FEATURES
1. While the door is closing, block one of the reversing
photoeyes. The door should stop immediately and reverse
to the fully open position. Repeat for second photoeye.
2. Pull chain hoist chain, door should go into a fault. Press
the open/reset button to clear fault.
CHECKLIST
1. Are door opening dimensions correct ?
2. Tracks shimmed as required?
3. Check for proper line voltage ?
4. Tracks aligned when installing wall fasteners ?
5. Are all mounting bolts tighten ?
6. Are the pillow block bearing set screws tightened to 66 to
80 in.-lb. ?
7. Is the open limit set so the curtain is out of the opening ?
8. All wires connected for the thru-beam photoeyes ?
9. Are loose wires secured away from moving parts?
10. With the power on, press the "OPEN" button, the door
should open and close automatically after a short delay. To
adjust the amount of door open time, the setting must be
changed in the i-COMM controller, Figure 21, Page 11.
11. Operate the door and observe the open and closed
positions. If it is necessary to adjust either position, shut
the power off and move the proper limit switch, Figure 32.
12. While the door is closing, break away the curtain to make
sure that the re-feed system is working.
13. While the door is closing, block the reversing photoeyes.
The door should reverse direction and move to the open
position, and then continue to operate.
14. Motor shroud installed.
OPERATING PROCEDURE / FINAL CHECKLIST
At startup for the FasTrax FR door with the curtain in the closed
position, the E-Vac blower should be allowed to remove air from
the curtain before the open button is pressed.
If curtain has been stored in the open position for an extended
period of time, the door should be closed to allow the E-Vac
system to remove air buildup.
IMPORTANT!!!
