MAINTENANCE PROCEDURES
RITE-HITE DOORS, INC. PLANNED MAINTENANCE
Model FASTRAX®
CUSTOMER: JOB# SERIAL# DATE:
Activation
Air Evacuation System (Freezer only)
(E-VAC)
Auto Re-Feed
Brake
Controls / Wiring
Curtain
Door Assembly
Door Operation
Drive Tube
Gearbox
Limit Switch Assembly
Lintel Seal
Motor
Non-Powered Opening Option
Photoeyes
Thermal Air Seal
Tracks (upper and lower)
Track Retention Edging
Virtual Vision
Vision
Recommended P.M. Intervals
(Time Shown In Months)
Operate all devices to verify proper operation.
With door closed, air should be removed from inside
the curtain. If billowing at bottom of curtain occurs,
check blower, tubing and connection to curtain.
Verify auto re-feed is operational.
Verify that brake stops the door at open and closed
positions as well as when stopped in the middle of
travel. To move the curtain manually, release the
brake by tightening the handle at the bottom of the
brake. The curtain should be able to be moved
manually. If brake is making noise, adjust.
Clean, check all connections with disconnect off.
Make sure all wires are free from moving parts.
Inspect for wear or damage, patch immediately to
prevent condensation buildup. Clean with isopropyl
alcohol or similar product. Check drive spheres, if
missing or damaged, replaced. Check top roller.
Perform visual inspection for damage.
Tighten all hardware. Replace any worn labels.
Use air hose to remove dust and debris.
Operate door and make sure all operations are
functioning properly.
Verify drive tube gear is centered over track groove.
Make sure bearing set screws and mounting bolts
are tight.
Check gearbox fluid level, fill with 90 weight if low.
Check snap rings to verify seated properly.
Check open and close positions, adjust as required.
Check photoeye cutoff switches.
Lubricate chain, sprockets and check alignment.
Verify lintel seal is sealing wall properly.
Check junction box and plug connections.
With power off, verify chain hoist opens door.
Lubricate chain, sprockets and check alignment.
Verify both photoeyes reverse the curtain.
LED’s on module or I-COMM should go on/off.
Clean emitter and receiver lens.
Verify air bag is inflated, free of tears and providing
an adequate seal against curtain and the wall.
If torn, patch immediately to prevent condensation
buildup. Verify warm air existing exhaust holes.
Perform visual inspection.
Verify proper width and tighten all hardware.
Check foam seal on exterior doors (opt interior).
Check for plastic dust or residue on the tracks or
edge wear, if so, lubricate with food grade synthetic
grease (Super Lube).
Inspect track retention edging, replace if cracked.
Verify virtual vision is functioning properly. Red
LED’s should be lit if movement on opposite side.
Inspect vision for tears or separation.
Clean with warm soapy water.
Planned Maintenance Task Inspect and Perform the Following
xxxx
1 6 12 18 24 30 36
MAINTENANCE INFO
High-Temperature Synthetic Grease with PTFE (Polytetrafluoroethylene)
The synthetic oil base in this food-grade silica-thickened grease, increases the time before the next application. It also
contains a PTFE additive that reduces friction and waterproofs metal surfaces, preventing rust and corrosion. NSF rated H1
for applications with incidental food contact. Temperature range is -45° to +450° F. Color is white.
McMaster Carr # 1378K33 - 14.1oz Cartridge
