RITROX RX1102 - Technical Specifications & Features

3
Technical Specifications & Features
Specifications
Model:
RX1101
Input: 110V~120V/60Hz or 220~240V/50Hz
Motor voltage: 24VDC
Power: 50W each actuator
Current: 2A
Actuator speed: 16mm/s
Max. actuator travel: 385mm
Ambient Temperature: -22°
~ 55°
(-4°F to 122°F)
Protection class: IP44
Features:
·Soft start and soft stop
·
Emergency release key in case of power failure
·
Dual/Single gate running mode
·
Adjustable opening/closing interval between master and slave gate
·
Stop in case of obstruction during gate opening.
·
Reverse in case of obstruction during gate closing.
·
Built in adjustable auto-close (0-99 seconds)
·Built in max. Motor running time (MRT) adjustable for multiple safety protection (1-50 seconds)
·
Digital display indicates the running situation and setting menu
·
Can be equipped with a wide range of accessories
·
Reliable electromagnetism limit for easy adjustment
·
Easy to install, and minimum maintenance requirement
RX1101
