Rittal VX Series User Manual

10 Sockel-System VX/Base/plinth system VX/Socles VX
TX30
4. Montage und Aufstellung
4. Assembly and siting
4. Montage et implantation
1.1
1.2
1
4.5 Anreihung
4.5 Baying
4.5 Juxtaposition
1.3
1
1.3
M = 12Nm -2/+0
Alternative
1.18660.00x 8660.02x
8660.03x
8660.03x
8660.140
siehe Abschnitt4.4
see section4.4
voir chapitre4.4
1.4

Rittal VX Series Specifications

General

Protection Class	IP55
Protection Category NEMA	NEMA 12
Finish	Powder-coated
Color	RAL 7035
Base/plinth	Optional
Approvals	UL, CSA
Door Options	Single door, Double door
Material	Steel
Width Options	600mm, 800mm, 1000mm, 1200mm
Height Options	2000mm, 2200mm
Depth Options	500mm, 600mm, 800mm
Mounting	Wall-mounted
