Rittal VX Series - Fixing to the Floor

11Sockel-System VX/Base/plinth system VX/Socles VX
D
W
B
A
≥ 40
≥ 40
1
1
2
1
Nennmaß
Nominal size
Valeur nominale
W/D mm
A/B mm
300 235
400 335
500 435
600 535
700 635
800 735
850 785
1000 935
1050 985
1100 1035
1200 1135
1600 1535
1800 1735
4. Montage und Aufstellung
4. Assembly and siting
4. Montage et implantation
4.6 Befestigung am Boden
4.6 Fixing to the floor
4.6 Ancrage au sol
2
2
2
2
2 Alternative
2
Alternative
8660.100
