Front Panel
Buttons 1 through 8 - These buttons turn function switches 1
through 8 on and off. The button lights up when the corresponding
function switch is on.
These function switches will control all footswitchable features of an
amplifier connected to the Mini Amp Gizmo. These features may
include channel, boost, effects loop or others – whichever features
are normally controlled using the amp’s footswitch.
The interface cable you use determines which button controls which
function. Please consult the instruction sheet that was included with
your cable to find the button to function mapping for your amp.
Write – When held down for 3 seconds, this button saves the current
switch state to non-volatile memory. This function is not active until
a Program Change message is received at the MIDI In jack. See the
MIDI Usage section for more details.
The Write button is always lit up with a green LED to indicate that the
Mini Amp Gizmo is on.
