RKC INSTRUMENT PF Series User Manual

6. PROGRAM CONTROL
IMR02L04-E3
6-24
6.9.2 Setting procedure
Select Signal type
[Engineering mode F80.04]
Select Time signal or Segment signal.
Set AT time signal
action
[Engineering mode F52.03]
Set Time signal action during Autotuning (AT).
(Common parameter setting item of Time signal and Segment signal)
Time signal
Segment signal
Set Time signal start
time
Set Time signal memory
group number
Set Time signal end
time
Segment signal
[Parameter setting mode]
Select Time signal memory group number
and then set memory for each Time signal.
Memory 1
Set Memories from 1 to 16
[Parameter setting mode]
Set Time signal memory group number for each pattern at Program
setting block.
Set for each pattern
[Parameter setting mode]
Set ON/OFF of Segment signal for each
segment at Program memory group setting
block.
Set for each segment
[Engineering mode]
Assign output for Time signal or Segment signal.
For details, refer to 6.2.1 Output assignment (OUT1 to OUT3) and
6.2.2 Digital output (DO) assignment (DO1 to DO12) of the PF900/
PF901 Instruction Manual (IMR02L03-E) on the CD-ROM.
Memory 16
Set Time signal output
assignment
Set Start segment of
time signal
Set Time signal
memory group setting
block
Set End segment of time
signal
Assign output
