6. PROGRAM CONTROL
IMR02L04-E3
6-25
6.9.3 Parameter setting
 Time signal type or Segment signal type
 Signal type [Engineering mode F80.04]
Select Time signal or Segment signal.
Parameter symbol Data range Factory set value
TS . TYP
0: Time signal type
1: Segment signal type
0
 Common parameter setting item of Time signal and Segment signal
 AT Time signal action [Engineering mode F52.03]
Set Time signal action during Autotuning (AT).
Parameter symbol Data range Factory set value
ATTS
0: Time signal OFF
1: Time signal ON
0
 Parameter setting item of Time signal
Settings related to Time signal are stored as Time signal memory group in the Parameter setting mode.
 Time signal memory group number [ Parameter setting mode: Program setting block ]
Set Time signal memory group number for each pattern.
Parameter symbol Data range Factory set value
TS . GR
0 to 16
0: No assignment
1
 Time signal output assignment
[Parameter setting mode: Time signal memory group setting block]
Set output assignment of Time signal for each memory.
Parameter symbol Data range Factory set value
01 . OUT
1 to 8: Time sugnal 1 to 8
0: No assignment
0
 Start segment of time signal
[Parameter setting mode: Time signal memory group setting block]
Set Start segment number of Time signal.
Parameter symbol Data range Factory set value
01 . S .S N
1 to 99
Within the maximum segment number.
1
 Time signal start time [ Parameter setting mode: Time signal memory group setting block ]
Set duration of Start time of Time signal start segment.
Parameter symbol Data range Factory set value
01 . S .T M
From 0:00 to 500:00 (Hour: Minute), or
from 0:00 to 500:00 (Minute: Second)
0 hour 00 minute
Set time unit at F80.05 in the Engineering mode. Refer to 4.5.5 Engineering mode (P. 4-43).
