RKC INSTRUMENT REX - C700 - Second Alarm (ALM2) Type Selection

-9-
(5) Second-alarm (ALM2) type selection ( )
Set-value (SV) display unit
VALUE DESCRIPTION
No second alarm
High alarm
Low alarm Deviation Second alarm (ALM2)
High / Low alarm alarm type selection
Band alarm (See page 10)
High alarm Process
Low alarm alarm
Without alarm hold action Second alarm (ALM2)
With alarm hold action hold action selection
C Instrument without the second alarm (ALM2).
C Instrument with the heater break alarm (HBA).
Cautions
1. The following instrument is set to “ ”.
C Instrument without the second alarm (ALM2).
C Instrument with the heater break alarm (HBA).
C Instrument which outputs control loop break alarm (LBA) from the second alarm side. [
setting details : For “ ” ]
2. “ ” setting displays are only “ ”and “ ”.
