-12-
(7) Energize / de-energize alarm selection etc. ( )
Set-value (SV) display unit
VALUE DESCRIPTION
Energize alarm Energize / de-energize
alarm selection
De-energize alarm (First alarm side)
Energize alarm Energize / de-energize
alarm selection
De-energize alarm (Second alarm side)
Without Z-124 specification Special specification
[Z-124] selection
With Z-124 specification ‰ (First alarm side)
Without Z-124 specification Special specification
[Z-124] selection
With Z-124 specification ‰ (Second alarm side)
‰ Z-124 specification : No alarm action caused by burnout is performed.
Cautions
1. Instrument without the first alarm (ALM1) and second alarm (ALM2) is set to “ ”.
C Instrument without the first alarm (ALM1).
[ setting details : For “ ”]
C Instrument without the second alarm (ALM2).
[ setting details : For “ ”]
2. “ ” setting displays are only “ ”and “ ”.
To Next Page
