2.3 E a c h P a r a m e t e r c h e c k s
(1) When all the settings are finished, press the key to check each parameter.
(2) When the contents of the initial setting are changed, change the model code plate stuck to inside of the controller and outside of the case
by referring to the following table.
(3) After each parameter has been checked, return the controller to the control mode by referring to “1.2 Exiting the initial set mode” (P.2).
MODEL CODE DESCRIPTION
REX-
C100
C400
C410
C700
C900
G G G G G G G
48 x 48 mm
96 x 48 mm
48 x 96 mm
72 x 72 mm
96 x 96 mm
Control action
F
D
W
A
PID action (Reverse action)
PID action (Direct action)
Heating / Cooling PID action (Water-cooling) i
Heating / Cooling PID action (Air-cooling) i
Input type G See page 16. Input Range Table “MODEL CODE”
Input range G See page 16. Input Range Table “MODEL CODE”
First control output [OUT(1)]
(Heating side)
M
V
8
G
Relay contact
Voltage pulse
Current 4 to 20mA DC
Trigger (for triac driving)
Second control output [OUT(2)]
(Cooling side)
None
M
V
8
No second control output (Control action : D, F)
Relay contact i
Voltage pulse i
Current 4 to 20mA DC i
First alarm (ALM1)
N
A
B
C
D
E
F
G
H
J
K
L
R
No first alarm (ALM1)
Deviation high alarm (without hold action)
Deviation low alarm (without hold action)
Deviation high / low alarm (without hold action)
Band alarm
Deviation high alarm (with hold action)
Deviation low alarm (with hold action)
Deviation high / low alarm (with hold action)
Process high alarm (without hold action)
Process low alarm (without hold action)
Process high alarm (with hold action)
Process low alarm (with hold action)
Control loop break alarm
Second alarm (ALM2)
N
A
B
C
D
E
F
G
H
J
K
L
P
S
No second alarm (ALM2)
Deviation high alarm (without hold action)
Deviation low alarm (without hold action)
Deviation high / low alarm (without hold action)
Band alarm
Deviation high alarm (with hold action)
Deviation low alarm (with hold action)
Deviation high / low alarm (with hold action)
Process high alarm (without hold action)
Process low alarm (without hold action)
Process high alarm (with hold action)
Process low alarm (with hold action)
Heater break alarm (CTL-6)
Heater break alarm (CTL-12)
‰ For the REX-C100, the content marked with i cannot be selection.
‰ When control output is trigger output for triac driving, only the first alarm is available (For the REX-C100).
