RKC INSTRUMENT REX - C700 - Engineering Unit and Cooling Type Selection

-6-
(2) Engineering unit and cooling type selection ( )
Set-value (SV) display unit
VALUE DESCRIPTION
EC Engineering unit
EF selection
Air-cooling (Type A) ‰ 1 Cooling type
Water-cooling (Type W) ‰ 2 selection
Fixed
‰ 1 Type A : Heating / cooling PID action (Air-cooling)
‰ 2 Type W : Heating / cooling PID action (Water-cooling)
Cautions
1. For the voltage and current input types, the engineering unit setting of EC or EF is ignored.
2. When control action is of the type D (PID action [direct action] or type F (PID action [reverse action] ), “Cooling
type selection” setting is ignored.
3. Do not set the upper 2 digits to numeric values other than “ ” since they are not used.
4. “ ” setting displays are only “ ”and “ ”.
