RKS MX25 - Shift System and Brake Adjustment

1.Push the pedal from the outsde to the
nsde, Then push down.
2.Then push down.
H. Adjustment of the Shft System
Please refer to User's Shft System Manual
J.Adjustment of the Brakes and the Brake Handles
There are two types of brakes: the v brakes and the dsc brake.
1.Tool: M5 hexagonal screwdrver
2.Please make sure a 3mm dstance between the wheel and the brake pads, and then adjust
(see the pcture below)
3.Please keep the brake n the mddle, and make sure the two brake pads work properly.
4.Level up the brakes (n ts standard condton)
1. Adjust the brake pads, to keep t
n lne wth the curve of the wheel.
2. Please make sure the brake pads
can have fully touch wth the
surface of the steel wheel.
1.Nuts for adjustment. Ths s for
the brakes to work properly.
2.If only one sde of the brakes
works, please adjust the nut.
11
COMPONENT ADJUSTMENT
MX25
