RM Italy BLA600 - Front Panel Overview; LCD Display; Power and VSWR Indicators; Front Panel Controls

1. LCD Display (2x16 character) 2. LED Output Power Bargraph 3. LED VSWR Level Bargraph 4. Enter key 5. Data key ’-’ 6. Data key ’+’ 7. Navigate key
BLA600 Front Panel
8. LED Warning / Protection 9. LED TX Indicator 10. ‘Standby’ / ‘Operate’ Key 11. Manual Band Select Keys 12. AC Mains ‘ON’ / ‘OFF’ Switch 13. RF Deck Cooling Intake 14. LPF Board / PSU Cooling Intake
