RM Italy BLA600 - Rear Panel Connectivity; Power Input and Fuse; Control Signal Connectors; Antenna I;O Connectors

BLA600 Rear Panel
1. AC Mains Inlet Socket 2. AC Line Fuse 3. ALC Min / Max Adjustment 4. ALC Output Connector (Phono / RCA Type) 5. PTT Input Connector (Phono / RCA Type) 6. Antenna 1 Output Connector (SO239) 7. Antenna 2 Output Connector (SO239) 8. Antenna 3 Output Connector (SO239)
9. AC Input Voltage Selection 10. Exhaust Grille LPF PCB 11. Exhaust Grille PSU 12. RTX Input Connector (SO239) 13. RF Deck Exhaust Grille 14. RF Ground Stud M5
3
