Roadmaster AddaBRAKE 8800 - Components and Diagrams; AddaBRAKE System Components

COMPONENTS
2
part
number description
1 9329 ....................brakepedalclamp
2 n/a .......................aircylindershaft
3 n/a .......................pressuregauge
4 n/a .......................regulatorcontrolknob
5 n/a .......................airreliefbutton
6 n/a .......................testbutton
7 650996.................adjustableseatpad
   (handleassembly)
8 450952.................adjustmentknob
9 450105.................adjustablefeet
10 450103.................12-voltpowercord
8
9
4
13
2
5
Itemsnotshowntoscale.
Optionalequipmentislistedinthe
“OptionalEquipment”section.
6
16
3
10
11
7
part
number description
11 650906.................AddaBRAKEwiringharness
12 650900.................breakawaywiringharness
13 8602 ....................breakawaycable
14 650898.................breakawayswitch
15 650906-01 ...........brakesignalwire
16 300065-00 ...........motorhomemonitorLED
17 9325 ....................audiosignalcircuitboard
18 450008.................motorhomemonitorpatch
   cord(notpictured)
1
15
17
12
14
