Roadmaster CRUISER - Parts Identification and Assembly; Component Identification and Specifications

14
Part name
Torque
(in. lb)
16 Rim -
17 Valve stem -
18 Spoke -
19 Wheel axle nut (front) 180-240
19A Wheel quick-release (opon) -
19B Wheel axle nut (rear) 240-300
20 Fork dropout -
21 Pedal 300-360
22 Crank arm 300
23 Chain guard -
24 Boom bracket lockring 300
25 Chain -
26 Chainwheel -
27 Freewheel -
28 Rear derailleur -
29 Back rack -
30 Linear brake assembly -
30A Brake cable pinch bolt 50-70
Part name
Torque
(in. lb)
1 Handlebar grip -
2 Rear brake lever 55 -70
3 Brake cable -
4 Shier cable -
5 Handlebar -
6 Front brake lever -
7 Stem binder bolt 100-120
8 Handlebar binder bolt(s) 145-200
9 Stem -
10 Headset 175-260
11 Caliper brake aaching nut 70-85
12 Caliper brake assembly 50-70
12A Brake cable pinch bolt 50-70
12B Brake pads -
12C Brake pads hardware 50-60
13 Front Fender -
14 Fork -
15 Tire -
Part name
Torque
(in. lb)
30B Brake pad -
30C Brake pad hardware 50-60
30D Brake spring -
30E Brake pivot bolt 17-20
31 Seat post clamp 60-80
31A Seat quick-release (opon) ?
32 Seat post -
33 Seat post aaching hardware 130-170
34 Saddle (seat) -
❷ Parts Idencaon
Cruiser Bicycle
Get to know the parts of your bicycle. This will help with assembly, maintenance, and troubleshoong. Color, style and parts may vary.
