Roadmaster CRUISER - Attach The Front Fender And Front Wheel

3 Assembly
20
Figure 3.7
ATTACH THE FRONT FENDER AND FRONT WHEEL
Therearetwotypesoffrontwheelandfenderassemblies;
nued wheel with at fender braceandquick-release with
rounded fender brace.Note:Quick-releasewheelsmaybeon
boththefrontandrearwheelsorjustone.Also,someretread
paernshaveadirecon,socompareyourfrontreandrear
reofthebicyclesothatbothtreadpaernsfacethesameway.
NuedFrontWheelwithFlatFenderBrace
❶Posionthefrontfendersothefenderbracketis
 ontheinsideoftheframe.Thefenderisaachedtothe
forkcrown.Aligntheholeinthebrackettotheholeinthe
forkcrown.Figure 3.7
❷Placeawasheronthescrewandinsertthescrewthrough
theholesinthebracketandforkcrown.

❸ Placeawasheronthescrew.
❹ Placethehexnutonthescrewandghten.
Washer
Fender
bracket
Washer
Hexnut
Flatfenderbrace
Screw
2
1
3
4
