Roadmaster CRUISER - Attach The Brake Cables

Assembly 3
19
19
Figure 3.4
Figure 3.5
Figure 3.6
Therearetwobrakeopons,Caliper and Linear Pull.

Followthesestepsifthebrakecablesarenotaachedtothe
brakelevers:
❶ Rotatethecableadjustmentbarrelandcablenutunlthe
slotsarealignedwiththeslotonthebrakeleverbody.
Figure 3.4
❷ Pressthebrakelevertowardsthegrip.
❸ Slidethebrakecablethroughtheslotsandplacethecable
headintothebrakelever.Figure 3.5
❹ Releasethebrakelever.Figure 3.6
❺ Lightlypullonthecableandrotatethecablenutandcable
barrelsotheyarenolongeraligned.
Note:SeeSecon 4: Adjusng the Brakesifadjustments
areneeded.
Failuretoproperlysetthebrakesmayresultintheinability
tostopthebicyclemovementandcauseseriousinjuryor
death.Besurethebrakesarefunconingproperlybefore
usingthebicycle.
ATTACH THE BRAKE CABLES
WARNING!
Cableadjustment
barrelslot
Cablenutslot
Brakecableslot Brakelever
Cablehead
Brakecable
