Roadmaster CRUISER - Page 23

Assembly 3
21
21
Figure 3.8
Figure 3.9 Figure 3.10
❺Posionthefrontwheelbetweenthefrontforklegswith
theaxleresnginsidetheforkdropout.Important!Besure
thewheelisascenteredaspossiblebetweentheforklegs.
Figure 3.8
❻ Placetheclipretainingwasherontheaxleandslideitup
againsttheforkdropout.Makesurethehookedendis
insidethesmallholeoftheforkdropout.Figure 3.9
❼ Inserttheendofeachfenderbraceovertheclipretaining
washer.Figure 3.10
❽ Placethetwoouteraxlenutsonandghtenevenly.Tighten
onesidepartway,thenghtentheothersideandrepeat
unlbothsidesareghtenedsecurely.Besurethatthe
wheelremainedcenteredbetweentheforklegs.
❾ Ifthewheelisocenter,loosentheaxlenutonthesidethat
hasasmallergapbetweenreandforkleganduseyour
handtopushthewheeltoacenteredposion;holdthe
wheelwithonehandandghtentheaxlenutandcheck
again.Repeatifneededtobesurethewheeliscentered
andsecurelyghtened.
Fork
dropout
Axlenut
Wheelcentered
betweenforks
Clipretaining
washer
Fenderbraces
7
5
6
8
