Roadmaster CRUISER - Page 24

3 Assembly
22
Figure 3.11
Quick-releaseFrontWheelwithRoundedFenderBrace
Ifyouhaveaquick-release front wheel with rounded fender
braceaachthefenderrst.
❶Posionthefrontfendersothefenderbracketis
 ontheinsideoftheframe.Thefenderisaachedtothefork
crown.Aligntheholeinthebrackettotheholeinthefork
crown.Figure 3.11
❷Placeawasheronthescrewandinsertthescrewthrough
theholesinthebracketandforkcrown.

❸ Placeawasheronthescrew.
❹ Placethehexnutonthescrewandghten.
❺Placetheroundedfenderbracesoverthesmallholeonthe
backoftheforkdropout.
❻Insertthesmallscrewsthroughtheroundedfenderbrace
andscrewintotheforkdropout.
❼ Posionthefenderandlooselyghtenthescrews.
❽ Aachthewheelandrmlyfastenthefenderinplace.
Washer
Roundedfenderbrace
Screw
Washer
Fender
bracket
Hexnut
2
1
3
4
6
5
