DMX protocol
1 2
Mode/channel
DMX
Value
Function
Type of
control
180-189 minus 1/2 green step
190 - 215 Forwards rainbow effect from fast to slow proportional
216 - 217 No rotation step
218 - 243 Backwards rainbow effect from slow to fast proportional
244 - 249
Random colour selection by audio control
step
244 - 249
Random colour selection by audio control
step
(Set microphone sensitivity in menu „Personality”)
250 - 255 Auto random colour selection from fast to slow proportional
10 *
Colour wheel 2 - fine positioning
0 - 255 Fine positioning proportional
11 9
Cyan
0 - 255 Cyan (0-white, 255-full cyan) proportional
12
10
Magenta
12
10
Magenta
0 - 255 Magenta (0-white, 255-full magenta) proportional
13 11
Yellow
0 - 255 Yellow (0-white, 255-full yellow) proportional
14 12
CTO filter
0 - 255 (0-6000K, 255-2700K) proportional
15
13
CMY +CTO + CW1+CW2 macros
15
13
CMY +CTO + CW1+CW2 macros
See table "Colour macros" to find components of each colour
The following channels are disabled: 7-14 (Mode 1),7-12 (Mode2)
0 - 7 No function step
8 - 9 Colour Macro 1 step
10-11 Colour Macro 2 step
12-13 Colour Macro 3 step
14-15
Colour Macro 4
step
14-15
Colour Macro 4
step
16-17 Colour Macro 5 step
18-19 Colour Macro 6 step
20-21 Colour Macro 7 step
22-23 Colour Macro 8 step
24-25 Colour Macro 9 step
26-27 Colour Macro 10 step
28-29 Colour Macro 11 step
30-31 Colour Macro 12 step
32-33 Colour Macro 13 step
34-35 Colour Macro 14 step
36-37 Colour Macro 15 step
38-39 Colour Macro 16 step
40-41
Colour Macro 17
step
40-41
Colour Macro 17
step
42-43 Colour Macro 18 step
44-45 Colour Macro 19 step
46-47 Colour Macro 20 step
48-49 Colour Macro 21 step
50-51 Colour Macro 22 step
52-53 Colour Macro 23 step
54-55
Colour Macro 24
step
54-55
Colour Macro 24
step
56-57 Colour Macro 25 step
58-59 Colour Macro 26 step
60-61 Colour Macro 27 step
62-63 Colour Macro 28 step
