DMX protocol
1 2
Mode/channel
DMX
Value
Function
Type of
control
160 - 169 Gobo wheels reset step
170 - 179 Dimmer/Shutter reset step
180 - 189 Zoom/focus/frost/prism reset step
190 - 199 Iris/framing shutters/effect wheel reset step
200 - 209
Total reset
step
200 - 209
Total reset
step
210 - 229
Reserved
230 - 239
Lamp Off step
240 - 255
Reserved step
7 7
Colour wheel 1
Continual positioning
0 Open/white proportional
18
Deep red
18
Deep red
proportional
37 Deep blue proportional
55 Orange proportional
73 Green proportional
91 Magenta proportional
110 Congo blue (UV) proportional
128-129
White
step
128-129
White
step
Positioning
130-139 Deep red step
140-149 Deep blue step
150-159 Orange step
160-169 Green step
170-179 Magenta step
180-189
Congo blue (UV)
step
180-189
Congo blue (UV)
step
190 - 215 Forwards rainbow effect from fast to slow proportional
216 - 217 No rotation step
218 - 243 Backwards rainbow effect from slow to fast proportional
244 - 249 Random colour selection by audio control step
(Set microphone sensitivity in menu „Personality”)
250 - 255 Auto random colour selection from fast to slow proportional
8 *
Colour wheel 1 - fine positioning
0 - 255 Fine positioning proportional
9 8
Colour wheel 2
Continual positioning
0 Open/white proportional
18 Pink proportional
37
Lavander
proportional
37
Lavander
proportional
55 Laser green proportional
73 CTB proportional
91 minus 1/1 green proportional
110 minus 1/2 green proportional
128-129 White step
Positioning
130-139
Pink
step
130-139
Pink
step
140-149 Lavander step
150-159 Laser green step
160-169 CTB step
170-179 minus 1/1 green step
