DMX protocol
1 2
Mode/channel
DMX
Value
Function
Type of
control
160-161
LEE 172 (Lagoon Blue)
step
162-163
LEE 179 (Chrome Orange)
step
164-165
LEE 180 (Dark Lavender)
step
166-167
LEE 181 (Congo Blue)
step
170-171
LEE 201 (Full C.T. Blue)
step
172-173
LEE 202 (Half C.T. Blue)
step
174-175
LEE 203 (Quarter C.T. Blue)
step
176-177
LEE 204 (Full C.T. Orange)
step
178-179
LEE 205 (Half C.T. Orange)
step
180-181
LEE 206 (Quarter C.T. Orange)
step
LEE 247 (LEE Minus Green)
LEE 247 (LEE Minus Green)
step
184-185
LEE 248 (Half Minus Green)
step
186-187
LEE 281 (Three Quarter C.T. Blue)
step
188-189
LEE 285 (Three Quarter C.T. Orange)
step
190-191
LEE 352 (Glacier Blue)
step
192-193
LEE 353 (Lighter Blue)
step
196-197
LEE 778 (Millennium Gold)
step
198-199
LEE 793 (Vanity Fair)
step
200-243
Reserved
244 - 249 Random macro selection by audio control
step
(Set microphone sensitivity in menu "PErsonality")
250 - 255 Auto random macro selection from fast to slow
proportional
Speed of CMY&CTO movement and Rot./Static Gobo selection
0-255 Speed of CMY+CTO movement from max. to min.
proportional
0-255 Speed of Rot. gobo & Static gobo selection from max. to min.
proportional
17 15
CMY+CTO+Colour wheel time
Time of CMY, CTO and Colour wheel movement (0.1sec-->25.5sec.)
Framing shutters+Zoom+Focus+Frost+Iris+Prism time
step
1 - 255
Time of framing shutters, zoom, focus, iris and frost
movement (0.1 sec-->25.5 sec.)
proportional
1-50
Time of prism movement (0.1 sec-->5 sec.)
20-127 Proportional indexing (73-center)
proportional
128-170 Ramping from open to full position ( max--->min. speed)
proportional
171-213 Ramping from open to half position ( max. --->min. speed)
proportional
214-255 Ramp. from half position to full position ( max. --->min. speed)
proportional
20 18
0 No rotation
step
1 - 127 Forwards rotation from fast to slow
proportional
128
No rotation -default
step
129 -255 Backwards rotation from slow to fast
proportional
21 19
