DMX protocol
1 2
Mode/channel
DMX
Value
Function
Type of
control
0-7 No animation
Note :
Set suitable DMX value at
Focus
channel to get desired
animation. All animations were created at distance 5 m from
screen with zoom=128DMX, Focus=200DMX
Coloured animations.
The channels are blocked: Colour wheel 1
and 2, CMY+CMY nacros, Effect wheel positioning, Effect wheel
and 2, CMY+CMY nacros, Effect wheel positioning, Effect wheel
rotation, stat. Gobo, Rotat. gobo, gobo rotation, Prism, Prism
rotation
8-9 Animation Macro 1 step
10-11 Animation Macro 2 step
12-13 Animation Macro 3 step
14-15 Animation Macro 4 step
16-17 Animation Macro 5 step
18-19 Animation Macro 6 step
20-21 Animation Macro 7 step
22-23 Animation Macro 8 step
24-25 Animation Macro 9 step
26-27 Animation Macro 10 step
Black and white animations
. The channels are blocked: Effect
wheel positioning, Effect wheel rotation, stat. Gobo, Rotat. gobo,
gobo rotation, Prism, Prism rotation
28-29 Animation Macro 1 step
30-31 Animation Macro 2 step
32-33 Animation Macro 3 step
34-35 Animation Macro 4 step
36-37
Animation Macro 5
step
36-37
Animation Macro 5
step
38-39 Animation Macro 6 step
40-41 Animation Macro 7 step
42-43 Animation Macro 8 step
44-45 Animation Macro 9 step
46-47 Animation Macro 10 step
48-255 Reserved
22
20
Static gobo wheel
22
20
Static gobo wheel
0-7 Open/hole step
Positioning
8-19 Gobo 1 step
20-31 Gobo 2 step
32-43 Gobo 3 step
44-55 Gobo 4 step
56-67 Gobo 5 step
68-79 Gobo 6 step
80-91 Gobo 7 step
92-103 Gobo 8 step
Shaking gobos from slow to fast
104-115 Gobo 1 proportional
116-127
Gobo 2
proportional
116-127
Gobo 2
proportional
128-139 Gobo 3 proportional
140-151 Gobo 4 proportional
152-163 Gobo 5 proportional
164-175 Gobo 6 proportional
