DMX protocol
1 2
Mode/channel
DMX
Value
Function
Type of
control
24 22
Rot. Gobo indexing/rotation
Gobo indexing - set position on channel 23/21
0 - 255 Gobo indexing proportional
Gobo rotation - set position on channel 23/21
0
No rotation
step
0
No rotation
step
1 - 127 Forwards gobo rotation from fast to slow proportional
128
No rotation - default
step
129 - 255 Backwards gobo rotation from slow to fast proportional
25 *
Rot. Gobo indexing/rotation - fine
0-255 Fine indexing (rotation) proportional
26 23
Prism
0 - 19
Open position (hole)
0 - 19
Open position (hole)
step
20 -49 6-facet linear prism -indexing step
50 - 75 6-facet linear prism - rotation step
76 - 105 6-facet circular prism- Indexing step
106-127 6-facet circular prism-rotation step
Prism/gobo macros
The channels are blocked: Prism, prism rot., rot. gobo, gobo rot.
128 - 135 Macro 1 step
136 - 143 Macro 2 step
144 - 151 Macro 3 step
152 - 159 Macro 4 step
160 - 167 Macro 5 step
168 - 175
Macro 6
step
168 - 175
Macro 6
step
176 - 183 Macro 7 step
184 - 191 Macro 8 step
192 - 199 Macro 9 step
200 - 207 Macro 10 step
208 - 215 Macro 11 step
216 - 223 Macro 12 step
224 - 231
Macro 13
step
224 - 231
Macro 13
step
232 - 239 Macro 14 step
240 - 247 Macro 15 step
248 - 255 Macro 16 step
27 24
Prism rotation
0 No rotation step
1 - 127
Forwards rotation from fast to slow
proportional
128
No rotation - default
step
129-255 Backwards rotation from slow to fast proportional
28 25
Frost
0
Open- default
step
Light
1-50 Frost from 0% to 100% proportional
51-53
100% frost
step
51-53
100% frost
step
54-63 Pulse closing from slow to fast proportional
64-73 Pulse opening from fast to slow proportional
74-83 Ramping from fast to slow proportional
84-86 Open step
