DMX protocol
1 2
Mode/channel
DMX
Value
Function
Type of
control
Medium
87-136 Frost from 0% to 100%
proportional
137-139 100% frost
step
140-149 Pulse closing from slow to fast
proportional
Pulse opening from fast to slow
Pulse opening from fast to slow
160-169 Ramping from fast to slow
proportional
170-172 Open
step
Heavy
173-222 Frost from 0% to 100%
proportional
223-225 100% frost
step
226-235 Pulse closing from slow to fast
proportional
Pulse opening from fast to slow
Pulse opening from fast to slow
proportional
246-255 Ramping from fast to slow
proportional
29 26
0 Open
step
1 - 179 From max.diameter to min.diameter
proportional
180 - 191 Closed
step
Pulse effects with Iris blackout:
Pulse effects with Iris blackout:
192 -219 Pulse opening from slow to fast
proportional
220 - 247 Pulse closing from fast to slow
proportional
248 - 249 Random pulse opening (fast)
step
250 - 251 Random pulse opening (slow)
step
252 - 253 Random pulse closing (fast)
step
254 - 255 Random pulse closing (slow)
step
0 - 255 Fine iris movement
proportional
31 27
0 - 255 Zoom from max. to min.beam angle
proportional
32 *
0-255 Fine zooming
proportional
33 28
0 - 255 Continuous adjustment from far to near
proportional
34 *
0- 255 Fine focusing
proportional
35 29 Reserved
Reserved for autofocus
36 30 Framing shutters module rotation
Rotation from left (0°) to 45°
Rotation from left (0°) to 45°
128 45°
step
129-255 Rotation from 45° to right (90°)
proportional
37 31 Framing shutter 1- movement
0-255 Movement from Outward to Inward
proportional
38 32 Framing shutter 1- swivelling
0-127 Swivelling from -25 degrees towards 0 degrees
proportional
129-255 Swivelling from 0 degrees to +25 degrees
proportional
39 33 Framing shutter 2- movement
0-255 Movement from Outward to Inward
proportional
40 34 Framing shutter 2- swivelling
