DMX protocol
1 2
Mode/channel
DMX
Value
Function
Type of
control
0-127 Swivelling from -25 degrees towards 0 degrees
proportional
128 0 degrees (default)
step
129-255 Swivelling from 0 degrees to +25 degrees
proportional
41 35 Framing shutter 3 movement
0-255
Movement from Outward to Inward
proportional
0-255
Movement from Outward to Inward
proportional
42 36 Framing shutter 3- swivelling
0-127 Swivelling from -25 degrees towards 0 degrees
proportional
128 0 degrees (default)
step
129-255 Swivelling from 0 degrees to +25 degrees
proportional
43 37 Framing shutter 4 movement
0-255 Movement from Outward to Inward
proportional
44
38
Framing shutter 4- swivelling
44
38
Framing shutter 4- swivelling
0-127 Swivelling from -25 degrees towards 0 degrees
proportional
128 0 degrees (default)
step
129-255 Swivelling from 0 degrees to +25 degrees
proportional
45 39
Framing shutters macros
0-3
No function
4-7
Macro 1
step
4-7
Macro 1
step
8-11
Macro 2
step
12-15
Macro 3
step
16-19
Macro 4
step
20-23
Macro 5
step
24-27
Macro 6
step
28-31
Macro 7
step
32-35
Macro 8
step
32-35
Macro 8
step
36-39
Macro 9
step
40-43
Macro 10
step
44-47
Macro 11
step
48-51
Macro 12
step
52-55
Macro 13
step
56-59
Macro 14
step
60-63
Macro 15
step
64-67
Macro 16
step
68-71
Macro 17
step
72-75
Macro 18
step
76-79
Macro 19
step
80-83
Macro 20
step
84-87
Macro 21
step
84-87
Macro 21
step
88-91
Macro 22
step
92-95
Macro 23
step
96-99
Macro 24
step
100-103
Macro 25
step
104-107
Macro 26
step
108-111
Macro 27
step
112-115
Macro 28
step
112-115
Macro 28
step
116-119
Macro 29
step
120-123
Macro 30
step
124-127
Macro 31
step
128-131
Macro 32
step
