DMX protocol
1 2
Mode/channel
DMX
Value
Function
Type of
control
132-135
Macro 33
step
136-139
Macro 34
step
140-143
Macro 35
step
144-147
Macro 36
step
148-151
Macro 37
step
148-151
Macro 37
step
152-155
Macro 38
step
156-159
Macro 39
step
160-163
Macro 40
step
164-167
Macro 41
step
168-171
Macro 42
step
172-175
Macro 43
step
176-179
Macro 44
176-179
Macro 44
step
180-183
Macro 45
step
184-187
Macro 46
step
188-191
Macro 47
step
192-195
Macro 48
step
196-199
Macro 49
step
200-203
Macro 50
step
200-203
Macro 50
step
204-207
Macro 51
step
208-211
Macro 52
step
212-255
Reserved
46 40
Framing shutters macro speed
0- 255 Speed from slow to fast. proportional
47 41
Shutter/ strobe
0 - 31
Shutter closed
step
0 - 31
Shutter closed
step
32 - 63 Shutter open step
64 - 95 Strobe-effect from slow to fast proportional
96 - 127 Shutter open step
128 - 143 Opening pulse in sequences from slow to fast proportional
144 - 159 Closing pulse in sequences from fast to slow proportional
160 - 191 Shutter open, Electronic strobing „ZAP” from slow to fast proportional
192 - 223 Random strobe-effect from slow to fast proportional
224 - 255 Shutter open step
48 42
Dimmer intensity
0 - 255 Dimmer intensity from 0% to 100% proportional
49 *
Dimmer intensity - fine
0 - 255 Fine dimming proportional
