DMX protocol

Mode/channel

DMX

Value

Function

Type of

control

85-86

Filter 164 (Flame Red)

step

87-88

Filter 165 (Daylight Blue)

step

89-90

Filter 169 (Lilac Tint)

step

91-92

Filter 170 (Deep Lavender)

step

93-94

Filter 172 (Lagoon Blue)

step

95-96

Filter 194 (Surprise Pink)

step

97-98

Filter 180 (Dark Lavender)

step

99-100

Filter 181 (Congo Blue)

step

101-102

Filter 197 (Alice Blue)

step

103-104

Filter 201 (Full C.T. Blue)

step

105-106

Filter 202 (Half C.T. Blue)

step

107-108

Filter 203 (Quarter C.T. Blue)

step

109-110

Filter 204 (Full C.T. Orange)

step

111-112

Filter 219 (Fluorescent Green)

step

113-114

Filter 206 (Quarter C.T. Orange)

step

115-116

Filter 247 (Filter Minus Green)

step

117-118

Filter 248 (Half Minus Green)

step

119-120

Filter 281 (Three Quarter C.T. Blue)

step

121-122

Filter 285 (Three Quarter C.T. Orange)

step

123-124

Filter 352 (Glacier Blue)

step

125-126

Filter 353 (Lighter Blue)

step

127-128

Filter 507 (Madge)

step

129-130

Filter 778 (Millennium Gold)

step

131-132

Filter 793 (Vanity Fair)

step

133-235 Raw DMX proportional

236-245 Rainbow effect (with fade time) from slow-> fast proportional

246-255 Rainbow effect (without fade time) from slow-> fast proportional

8 8

Red/Cyan (8 bit)*

0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional

9 *

Red/Cyan (16bit)*

0 - 255 Colour saturation control - fine (255=default) proportional

10 9

Green/Magenta (8 bit) *

0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional

11 *

Green/Magenta (16bit) *

0 - 255 Colour saturation control - fine (255=default) proportional

12 10

Blue/Yellow (8 bit) *

0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional

13 *

Blue/ Yellow (16bit) *

0 - 255 Colour saturation control - fine (255=default) proportional

14 11

White (8 bit)

If RGBW mode is selected:

0-255 Colour saturation control - coarse 0-100% (255=default) proportional

If CMY mode is selected:

0 - 255 No function

15 *

White (16 bit)

0 - 255 Colour saturation control - fine (255=default) proportional

16 12

CTC

If function "White Point 8000K" is ON

0-255 Col. temperature correction from 8000K to 2700K -for whites only proportional

Page 3
