Mode/channel
DMX
Value
Function
Type of
control
(0=8000K, 64=5600K, 128=4200K, 192=3200K, 255=2700K)
To get colour temperatures stated above, RGBW channels have to
be set at the same value e.g. 255DMX (0=default)
(To activate Tungsten effect at 2700K and 3200K , set DMX value at
"Power/Special functions" channel)
If function "White Point 8000K" is OFF
0-255 Colour temperature correction for from cool white to 2700K proportional
17 13
Defines relation between colour channels
"Virtual" = Virtual Colours (Virtual Colour Wheel)
"Colour mix" = Colour channels (RGBW/CMY)
0-9 Virtual colors ("Virtual" has priority) step
10-19 Maximum mode (highest values have priority) step
20-29 Minimum mode (lowest values have priority) step
30-39 Multiply mode (multiply Virtual and Colour Mix) step
40-49 Addition mode (Virtual + Colour mix) (45=default) step
50-59 Subtraction mode (Virtual – Colour mix) step
60-69 Inverted Subtraction mode (Virtual – Colour mix) step
70-128 Reserved
129 Virtual colors (virtual has priority) step
130-254 Crossfade (crossfade between Virtual and Colour mix) proportional
255 Colour channels ("Colour mix" has priority) step
18 14
0-255 Zoom from max. to min.beam angle (128=default) proportional
19 *
0-255 Fine zooming (0=default) proportional
20 15
0 - 31 Shutter closed step
32 - 63 Shutter open (32=default) step
64 - 95 Strobe-effect from slow to fast proportional
96 - 127 Shutter open step
128 - 143 Opening pulse in sequences from slow to fast proportional
144 - 159 Closing pulse in sequences from fast to slow proportional
160 - 191 Shutter open step
192 - 223 Random strobe-effect from slow to fast proportional
224 - 255 Shutter open step
21 16
0 - 255 Dimmer intensity from 0% to 100% (0=default) proportional
22 *
Dimmer intensity - fine (16 bit)
0 - 255 Fine dimming (0=default) proportional
*Select RGB or CMY mixing mode on channel "Power/Special functions" .
