Robe Robin MiniMe - DMX Protocol

DMX protocol
Channel
1
Pan
0 - 255 Pan movement by 450° proportional
2
Pan fine
0 - 255 Fine control of pan movement proportional
3
Tilt
0 - 255 Tilt movement by 270° proportional
4
Tilt fine
0 - 255 Fine control of tilt movement proportional
5
Pan/Tilt speed , Pan/Tilt time
0 Standard mode step
1 Max. Speed Mode step
Pan/Tilt speed mode
2 - 255 Speed from max. to min. proportional
Pan/Tilt time mode
2 - 255 Time from 0.2 s to 25.5 sec. proportional
6
Special functions
To activate following functions, stop in DMX value for at least 3 s
and shutter must be closed at least 3 sec. („Shutter,Strobe”
channel 23 must be at range: 0-31 DMX). Corresponding menu
items are temporarily overriden).
0-49 Reserved
50 - 59 Pan/Tilt speed mode step
60 - 69 Pan/Tilt time mode step
70 - 79 Blackout while pan/tilt moving step
80 - 89 Disabled blackout while pan/tilt moving step
90-94
Ceiling projection On
step
95-99
Ceiling projection Off
step
100-104
Rear projection On
step
105-109
Rear projection Off
step
110 - 129 Reserved
To activate following functions, stop in DMX value for at least 3
seconds.
130-134
Keep aspect ratio On
step
135-139
Keep aspect ratio Off
step
140 - 149 Pan/Tilt reset step
150 - 179 Reserved
180 - 189 Focus reset step
190 - 199 Graphic engine reset(software update executing) step
200 - 209 Total reset step
210-219 Internal HDMI step
220-229 External HDMI step
230-234 Save AutoKeystoning step
235 - 255
Reserved
7
Digital zoom
0-127
Zoom from min. -->real size proportional
128
real size (default) step
129-255
Zoom from real size -->max. proportional
8
Focus
0 - 255 Continuous adjustment from far to near proportional
Robin MiniMe - DMX protocol, version 1.2
DMX
Value
Function
Type of
control
Page 1
