DMX protocol
Channel
DMX
Value
Function
Type of
control
9
Keystoning Vertical
0-255
Vertical keystoning (128 Default)
proportional
10
Keystoning Horizontal
0 - 255
Horizontal keystoning (128 Default)
proportional
11
Cyan
0 - 255 Cyan (white-->full cyan) proportional
12
Magenta
0 - 255 Magenta (white-->full magenta) proportional
13
Yellow
0 - 255 Yellow (white-->full yellow) proportional
14
Virtual colour wheel
0-15 White (8000K) step
16 Blue step
17-55 Blue ---> Cyan proportional
56 Cyan step
57-95 Cyan ---> Green proportional
96 Green step
97-134 Green ---> Yellow proportional
135 Yellow step
136-174 Yellow ---> Red proportional
175 Red step
176-214 Red ---> Magenta proportional
215 Magenta step
216-246
Magenta ---> Blue
proportional
247 Blue step
248-255 Reserved
15
Colour Effect wheel
0 No function step
Static effects
1 Horizontal linear shade, white-->black step
2 Horizontal Linear shade, black-->white step
3 Vertical linear shade, black-->white step
4 Vertical linear shade, white-->black step
5 Diagonal shade, white -->black step
6 Diagonal shade, black -->white step
7 Horizontal linear shade, white-->red step
8 Horizontal Linear shade, red-->white step
9 Vertical linear shade, red-->white step
10 Vertical linear shade, white-->red step
11 Diagonal shade, white -->red step
12 Diagonal shade, red -->white step
13 Horizontal linear shade, white-->green step
14 Horizontal Linear shade, green-->white step
15 Vertical linear shade, green-->white step
16 Vertical linear shade, white-->green step
17 Diagonal shade, white -->green step
18 Diagonal shade, green -->white step
19 Horizontal linear shade, white-->blue step
20 Horizontal Linear shade, blue-->white step
21 Vertical linear shade, blue-->white step
