Robe Robin MiniMe - Page 35

DMX protocol
Channel
DMX
Value
Function
Type of
control
22 Vertical linear shade, white-->blue step
23 Diagonal shade, white -->blue step
24 Diagonal shade, blue -->white step
25 Horizontal linear shade, white-->cyan step
26 Horizontal Linear shade, cyan-->white step
27 Vertical linear shade, cyan-->white step
28 Vertical linear shade, white-->cyan step
29 Diagonal shade, white -->cyan step
30 Diagonal shade, cyan -->white step
31 Horizontal linear shade, white-->magenta step
32 Horizontal Linear shade, magenta-->white step
33 Vertical linear shade, magenta-->white step
34 Vertical linear shade, white-->magenta step
35 Diagonal shade, white -->magenta step
36 Diagonal shade, magenta -->white step
37 Horizontal linear shade, white-->yellow step
38 Horizontal Linear shade, yellow-->white step
39 Vertical linear shade, yellow-->white step
40 Vertical linear shade, white-->yellow step
41 Diagonal shade, white -->yellow step
42 Diagonal shade, yellow -->white step
43 RGBW shades step
44 CMYW shades step
45 RGBY shades step
46 RMBG shades step
47-49 Reserved
Dynamic effects
50 Colour changing black -->white, slowly step
51 Colour changing black -->white, fast step
52 Colour changing red -->white, slowly step
53 Colour changing red -->white, fast step
54 Colour changing green -->white, slowly step
55 Colour changing green -->white, fast step
56 Colour changing blue -->white, slowly step
57 Colour changing blue -->white, fast step
58 Colour changing yellow -->white, slowly step
59 Colour changing yellow -->white, fast step
60 Colour changing magenta -->white, slowly step
61 Colour changing magenta -->white, fast step
62 Colour changing cyan -->white, slowly step
63 Colour changing cyan -->white, fast step
64 Colour changing (slow) red -->green -->blue -->yellow step
65 Colour changing (fast) red -->green -->blue -->yellow step
65 Colour changing (fastest) red -->green -->blue -->yellow step
66-69 Reserved
70 Horizontal linear shade, white-->black and vice versa, slowly step
71 Horizontal linear shade, white-->black and vice versa,fast step
72 Vertical linear shade, white-->black and vice versa, slowly step
73 Vertical linear shade, white-->black and vice versa, fast step
74 Diagonal shade, black -->white and vice versa, slowly step
