DMX protocol
Channel
DMX
Value
Function
Type of
control
75 Diagonal shade, black -->white and vice versa, fast step
76 Shade black -->white, slow rotation, clockwise step
77 Shade black -->white, fast rotation, clockwise step
78 Shade black -->white, slow rotation, anticlockwise step
79 Shade black -->white, fast rotation, anticlockwise step
80 Horizontal linear shade, white-->red and vice versa, slowly step
81 Horizontal linear shade, white-->red and vice versa,fast step
82 Vertical linear shade, white-->red and vice versa, slowly step
83 Vertical linear shade, white-->red and vice versa, fast step
84 Diagonal shade, red -->white and vice versa, slowly step
85 Diagonal shade, red -->white and vice versa, fast step
86 Shade red -->white, slow rotation, clockwise step
87 Shade red -->white, fast rotation, clockwise step
88 Shade red -->white, slow rotation, anticlockwise step
89 Shade red -->white, fast rotation, anticlockwise step
90 Horizontal linear shade, white-->green and vice versa, slowly step
91 Horizontal linear shade, white-->green and vice versa,fast step
92 Vertical linear shade, white-->green and vice versa, slowly step
93 Vertical linear shade, white-->green and vice versa, fast step
94 Diagonal shade, green -->white and vice versa, slowly step
95 Diagonal shade, green -->white and vice versa, fast step
96 Shade green -->white, slow rotation, clockwise step
97 Shade green -->white, fast rotation, clockwise step
98 Shade green -->white, slow rotation, anticlockwise step
99 Shade green -->white, fast rotation, anticlockwise step
100 Horizontal linear shade, white-->blue and vice versa, slowly step
101 Horizontal linear shade, white-->blue and vice versa,fast step
102 Vertical linear shade, white-->blue and vice versa, slowly step
103 Vertical linear shade, white-->blue and vice versa, fast step
104 Diagonal shade, blue -->white and vice versa, slowly step
105 Diagonal shade, blue -->white and vice versa, fast step
106 Shade blue -->white, slow rotation, clockwise step
107 Shade blue -->white, fast rotation, clockwise step
108 Shade blue -->white, slow rotation, anticlockwise step
109 Shade blue -->white, fast rotation, anticlockwise step
110 Horizontal linear shade, white-->cyan and vice versa, slowly step
111 Horizontal linear shade, white-->cyan and vice versa,fast step
112 Vertical linear shade, white-->cyan and vice versa, slowly step
113 Vertical linear shade, white-->cyan and vice versa, fast step
114 Diagonal shade, cyan -->white and vice versa, slowly step
115 Diagonal shade, cyan -->white and vice versa, fast step
116 Shade cyan -->white, slow rotation, clockwise step
117 Shade cyan -->white, fast rotation, clockwise step
118 Shade cyan -->white, slow rotation, anticlockwise step
119 Shade cyan -->white, fast rotation, anticlockwise step
120 Horizontal linear shade, white-->magenta and vice versa, slowly step
121 Horizontal linear shade, white-->magenta and vice versa,fast step
122 Vertical linear shade, white-->magenta and vice versa, slowly step
123 Vertical linear shade, white-->magenta and vice versa, fast step
124 Diagonal shade, magenta -->white and vice versa, slowly step
