DMX protocol
Channel
DMX
Value
Function
Type of
control
175 Horizontal/Vertical/Diagonal colour transition fast step
176-255 Reserved
16
Digital gobo wheel selection
0-31 Default-Factory Digital gobo wheel step
32-63 Internal Custom Digital gobo wheel step
64-95 External Custom Digital gobo wheel (USB memory stick) step
96-255 Reserved (for future functions)
17
Digital gobo wheel
0
Open
step
1-250
Gobos/videos (by one DMX value:1,2,3…...250)
proportional
The following distribution serves for factory gobos/videos only
1-59
Black and white gobos (by one DMX value: 1, 2, 3…..59)
proportional
60-202
Colour pictures (by one DMX value: 60, 61, 62…..202)
proportional
203-216
Animations (by one DMX value: 203, 204, 2050…216)
proportional
To activate following two functions, set a transition effect (1-48)
at Effect Wheel - channel 21
251
Gobos presentation (gobos selected randomly)
step
252
Gobos presentation (gobos selected in alphabetical order)
step
253-255 Reserved
18
Video speed control
0 Original speed step
1 Standing in first frame step
2-254 Speed from min. to max. proportional
255 Original speed step
19
Digital gobo indexing and rotation
0 - 127 Gobo indexing proportional
128-191 Forwards gobo rotation from fast to slow proportional
192-193 No rotation step
194- 255 Backwards gobo rotation from slow to fast proportional
20
Digital gobo gobo indexing and rotation fine
0-255 Fine indexing (rotation) proportional
21
Effect wheel
The following effects are controlled by means of the "Effect
speed/Time" channel below. Type of control is stated in the
column on the right.
0 Open position (hole) step
Transition effects between two gobos (pictures)
1 Random transition 1
2 Transition with blending 1
3 Transition from left --> right, horizontally 1
4 Transition from right --> left, horizontally 1
5 Stripe transition from left --> right, horizontally 1
6 Stripe transition from right -->left, horizontally 1
7 3-stripe transition from left-->right, horizontally 1
8 3-stripe transition from right-->left, horizontally 1
9 6-stripe transition from left-->right, horizontally 1
10 6-stripe transition from right-->left, horizontally 1
11 Transition up --> down, vertically 1
12 Transition down -->up, vertically 1
13 Stripe transition up --> down, vertically 1
14 Stripe transition down -->up, vertically 1
