DMX protocol
Channel
DMX
Value
Function
Type of
control
15 3-stripe transition up-->down, vertically 1
16 3-stripe transition down-->up, vertically 1
17 6-stripe transition up-->down, vertically 1
18 6-stripe transition down-->up, vertically 1
19 Transition 2 from left --> right, horizontally (diffusion edge) 1
20 Transition 2 from right --> left, horizontally (diffusion edge) 1
21 Transition 2 up --> down, vertically (diffusion edge) 1
22 Transition 2 down -->up, vertically (diffusion edge) 1
23 Iris transition out--> in 1
24 Iris transition in--> out 1
25 Iris transition out--> in (Diffusin edge) 1
26 Iris transition in--> out (Diffusion edge) 1
27 Iris transition 3 out--> in (more diffusion edge) 1
28 Iris transition 3 in--> out (more diffusion edge) 1
29 Moving transition from left --> right 1
30 Moving transition from left --> right 1
31 Moving transition up --> down 1
32 Moving transition from down --> up 1
33 Drop transition 1
34 Simple transition 1
35 Pixel transition 1
36 Transition via blending 1
37 Transition with white output 1
38 Crossing transition 1
39 Picture in picture transition 1
40 Direct transition 1
41 Transition with vertical rotation 1
42 Transition with horizontal rotation 1
43 Transition with diagonal rotation 1
44 Transition with diagonal rotation-opposite direction 1
45 Zoom out transition 1
46 Zoom in transition 1
47 Zoom transition in horizontal direction 1
48 Zoom transition in vertical direction 1
49-79 Reserved
Effects applied at one gobo (picture)
80 Kaleidoscope 1 3
81 Kaleidoscope 2 3
82 Kaleidoscope 3 3
83 Kaleidoscope 4 3
84 Kaleidoscope 5 3
85 Sunflower Kaleidoscope (coarse) 3
86 Sunflower Kaleidoscope (soft) 3
87 Sunflower kaleidoscope (slow) 4
88 Sunflower kaleidoscope (faster) 4
89 Sunflower kaleidoscope (fastest) 4
90-99 Reserved
100 Circle Iris in/out 2
101 Circle Iris in/out (diffusion edge) 2
102 Vertical Ellipse Iris in/out 2
