0 - 255 Pan movement by 540°/360° (128=default)
proportional
2 2
0 - 255 Fine control of pan movement (0=default)
proportional
3 3
0 - 255 Tilt movement by 360° (128=default)
proportional
4 4
0 - 255 Fine control of tilt movement (0=default)
proportional
5 5
0 Pan range 540°, shortcut Off (0=default)
step
1 Pan range 360°, shortcut On
step
2-127
No function
(Pan range 540°, shortcut Off)
128-189 Continuous rotation fast -> slow , Forwards
proportional
190-193 Stop rotation
step
194-255 Continuous rotation slow -> fast , Backwards
proportional
6 6
0 Tilt range 360°, Shortcut Off (0=default)
step
1 Tilt range 360°, Shortcut On
step
2-127
No function
(Tilt range 360°, Shortcut Off)
128-189 Continuous rotation fast -> slow , Forwards
proportional
190-193 Stop rotation
step
194-255 Continuous rotation slow -> fast , Backwards
proportional
7 7
Pan/Tilt speed , Pan/Tilt time
0 Max. speed -tracking mode (0=default)
step
Pan/Tilt speed
1 - 255 Speed from max. to min. (vector mode)
proportional
Pan/Tilt time
1 - 255 Time from 0.1 s to 25.5 sec.
proportional
8 8
0 -19 Reserved (0=default)
To activate following functions, stop in DMX value for at least 3 s
and shutter must be closed at least 3 sec. („Shutter,Strobe”
channel 25/20 must be at range: 0-31 DMX). Corresponding menu
items are temporarily overriden.
20-24
Display ON
step
25-29
Display OFF
step
30-34
RGBW colour mixing mode
step
35-39
CMY colour mixing mode
step
40-44 Pan/Tilt speed mode
step
45 - 49 Pan/Tilt time mode
step
50 -54 Blackout while pan/tilt moving
step
55 -59 Disabled blackout while pan/tilt moving
step
60 - 64 Dimmer curve - square law
step
65 - 69 Dimmer curve - linear
step
70 - 74
Fans mode: Auto
step
75 - 79
Fans mode: High
step
80-84
White point 8000K ON
step
85-89
White point 8000K OFF
step
Robin SPIKIe - DMX protocol
Version: 1.1
Mode 1-Standard 16-bit, Mode 2 -Reduced 8-bit
Mode/channel
DMX
Value
Function
Type of
control
Page 1
