DMX protocol
1 2
Mode/channel
DMX
Value
Function
Type of
control
90 -129
Reserved
To activate following functions, stop in DMX value for at least 3
seconds.
130 - 139 Fixture reset (except pan/tilt)
140 - 149 Pan/Tilt reset step
150 - 159 Zoom reset step
160 - 169 Flower effect/prism reset step
170-171 Tungsten effect simulation (750W) On step
172-173 Tungsten effect simulation (1000W) On step
174-175 Tungsten effect simulation (1200W) On step
176-177 Tungsten effect simulation (2000W) On step
178-179 Tungsten effect simulation (2500W) On step
180-181 Tungsten effect simulation Off step
182 - 199 Reserved
200 - 209 Total fixture reset step
210 - 255 Reserved
9 9
Virtual colour wheel
0 No function (0=default) step
1-2
LEE 4 (Medium Bastard Amber)
step
3-4
LEE 25 (Sunset Red)
step
5-6
LEE 19 (Fire)
step
7-8
LEE 26 (Bright Red)
step
9-10
LEE 58 (Lavender)
step
11-12
LEE 68 (Sky Blue)
step
13-14
LEE 36 (Medium Pink)
step
15-16
LEE 89 (Moss Green)
step
17-18
LEE 88 (Lime Green)
step
19-20
LEE 90 (Dark Yellow Green)
step
21-22
LEE 49 (Medium Purple)
step
23-24
LEE 52 (Light Lavender)
step
25-26
LEE 102 (Light Amber)
step
27-28
LEE 103 (Straw)
step
29-30
LEE 140 (Summer Blue)
step
31-32
LEE 124 (Dark Green)
step
33-34
LEE 106 (Primary Red)
step
35-36
LEE 111 (Dark Pink)
step
37-38
LEE 115 (Peacock Blue)
step
39-40
LEE 126 (Mauve)
step
41-42
LEE 117 (Steel Blue)
step
43-44
LEE 118 (Light Blue)
step
45-46
LEE 122 (Fern Green)
step
47-48
LEE 182 (Light Red)
step
49-50
LEE 121 (LEE Green)
step
51-52
LEE 128 (Bright Pink)
step
53-54
LEE 131 (Marine Blue)
step
55-56
LEE 132 (Medium Blue)
step
57-58
LEE 134 (Golden Amber)
step
59-60
LEE 135 (Deep Golden Amber)
step
61-62
LEE 136 (Pale Lavender)
step
63-64
LEE 137 (Special Lavender)
step
