DMX protocol
1 2
Mode/channel
DMX
Value
Function
Type of
control
If RGBW mode is selected:
0-255 Colour saturation control - coarse 0-100% (255=default)
proportional
If CMY mode is selected:
0 - 255 No function
17 *
0 - 255 Colour saturation control - fine (255=default)
proportional
18 14
If function "White Point 8000K" is ON
0-255
Col. temperature correction from 8000K to 2700K -for whites only proportional
(0=8000K, 64=5600K, 128=4200K, 192=3200K, 255=2700K)
To get colour temperatures stated above, RGBW channels have to
be set at the same value e.g. 255DMX (0=default)
(To activate Tungsten effect at 2700K and 3200K , set DMX value
at "Power/Special functions" channel)
If function "White Point 8000K" is OFF
0-255 Colour temperature correction for from cool white to 2700K
proportional
19 15
Defines relation between colour channels
"Virtual" = Virtual Colours (Virtual Colour Wheel)
"Colour mix" = Colour channels (RGB/CMY)
0-9 Virtual colors (virtual has priority)
step
10-19 Maximum mode (highest values have priority)
step
20-29 Minimum mode (lowest values have priority)
step
30-39 Multiply mode (multiply Virtual and Colour Mix)
step
40-49 Addition mode (Virtual + Colour mix)
step
50-59 Subtraction mode (Virtual – Colour mix)
step
60-69 Inverted Subtraction mode (Virtual –Colour mix)
step
70-128 Reserved
129 Virtual colors (virtual has priority)
step
130-254 Crossfade (crossfade between Virtual and Colour mix)
proportional
255 Colour channels ("Colour mix" has priority) -default step
0 Open position-without prism (0=default)
step
1 - 127 Prism inserted, forwards rotation from fast to slow
proportional
128 No rotation-prism inserted
step
129-255 Prism inserted, backwards rotation from slow to fast
proportional
Flower Effect & Prism/Flower Effect macros
0-19 Without Flower Effect (0=default)
step
20-49 Flower Effect
step
In range of 50-69DMX, channels Rotating prism and Flower Effect
rotation are blocked
50-51 Macro 1
step
52-53 Macro 2
step
54-55 Macro 3
step
56-57 Macro 4
step
58-59 Macro 5
step
60-61 Macro 6
step
62-63 Macro 7
step
64-65 Macro 8
step
66-67 Macro 9
step
Page 4
