DMX protocol
1 2
Mode/channel
DMX
Value
Function
Type of
control
68-69 Macro 10 step
70-255 Reserved
22 18
Flower effect rotation
0 No rotation step
1 - 127 Forwards rotation from fast to slow proportional
128 No rotation (128=default) step
129-255 Backwards rotation from slow to fast proportional
23 19
Zoom
0-255 Zoom from max. to min.beam angle (128=default) proportional
24 *
Zoom - fine
0-255 Fine zooming (0=default) proportional
25 20
Shutter/ strobe
0 - 31 Shutter closed step
32 - 63 Shutter open (32=default) step
64 - 95 Strobe-effect from slow to fast proportional
96 - 127 Shutter open step
128 - 143 Opening pulse in sequences from slow to fast proportional
144 - 159 Closing pulse in sequences from fast to slow proportional
160 - 191 Shutter open step
192 - 223 Random strobe-effect from slow to fast proportional
224 - 255 Shutter open step
26 21
Dimmer intensity (8 bit)
0 - 255 Dimmer intensity from 0% to 100% (0=default) proportional
27 *
Dimmer intensity - fine (16 bit)
0 - 255 Fine dimming (0=default) proportional
* Select RGB or CMY mixing mode on channel "Power/Special functions"
