DMX protocol
1 2 3
33 23 37 32
34 24 38 0
35 * 39 0
1 2 3
1 1 1
Pan
0 - 255 Pan movement by 540° (128=default) proportional
2 2 2
Pan Fine
0 - 255 Fine control of pan movement (0=default) proportional
3 3 3
Tilt
0 - 255 Tilt movement by 280° (128=default) proportional
4 4 4
Tilt fine
0 - 255 Fine control of tilt movement (0=default) proportional
5 5 5
Pan/Tilt speed , Pan/Tilt time
0 Standard mode (0=default) step
1 Max. Speed Mode step
Pan/Tilt speed mode
2 - 255 Speed from max. to min. proportional
Pan/Tilt time mode
2 - 255 Time from 0.2 sec. to 25.5 sec. proportional
6 6 6
Power/Special functions
Factory display menu setting: DMX Input-Wired ,Graphic display-
On, Pan/tilt Mode-Speed,Blackout while pan/tilt moving-Off, Fans
mode-Auto
0 -9 Reserved (0=default)
To activate following functions, stop in DMX value for at least 3 s and
shutter must be closed at least 3 sec. („Shutter,Strobe” channel 35/35/39
must be at range: 0-31 DMX). Corresponding menu items are temporarily
overriden.
10-14
DMX input: Wired DMX *
step
15-19
DMX input: Wireless DMX *
step
* function is active only 10 seconds after switching the fixture on
20-24
Graphic display: On
step
25-29
Graphic display: Off
step
30-39
Reserved
40-44 Pan/Tilt mode: Speed step
45-49 Pan/Tilt mode: Time step
50-54 Blackout while pan/tilt moving: On step
55-59 Blackout while pan/tilt moving: Off step
60-69 Reserved
70-74
Fans mode: Auto
step
75-79
Fans mode: High
step
80-119
Reserved
120-124 Parking position On step
125-129 Parking position Off step
To activate following functions, stop in DMX value for at least 3 seconds.
Mode/channel
Default
DMX Value
Function
Shutter/ strobe
Dimmer intensity
Dimmer intensity - fine
Mode/channel
DMX
Value
Function
Type of
control
