DMX protocol
1 2 3
Mode/channel
DMX
Value
Function
Type of
control
130 - 139 Fixture reset (except pan/tilt)
140 - 149 Pan/Tilt reset step
150 - 179 Reserved
180 - 189 Zoom/focus/frost/prism reset step
190 - 199 Barndoors/scrim reset step
200 - 209 Total fixture reset step
210-239
Reserved
240 Disabled "Quiet mode" step
241 - 255 "Quiet mode" - fan noise control from min. to max. proportional
7 * 7
Factory display menu setting: 600Hz
Select PWM output frequency of LEDs. Selected PWM frequency can be
fine adjusted in 127 steps up/down around selected PWM frequency on
the channel below. Corresponding menu item (Frequency Setup) is
temporarily overriden.
0-4
PWM frequency from Display menu (fixture utilizes PWM
step
frequency set in the display menu item Frequency Setup).
5-9 300 Hz step
10-14 600 Hz (10=default) step
15-19 1200 Hz step
20-24 2400 Hz step
25-255
Reserved (fixture utilizes PWM frequency set in the display menu item
Frequency Setup).
8 * 8
LED frequency fine adjusting
Factory display menu setting: 600Hz
Select desired PWM output frequency of LEDs on the channel above.
0-1 Selected LED Frequency step
2 LED Frequency (step -126) step
3 LED Frequency (step -125) step
4 LED Frequency (step -124) step
:
125 LED Frequency (step -3) step
126 LED Frequency (step -2) step
127 LED Frequency (step -1) step
128
Selected LED Frequency (128=default)
step
129 LED Frequency (step +1) step
130 LED Frequency (step +2) step
131 LED Frequency (step +3) step
:
252 LED Frequency (step +124) step
253 LED Frequency (step +125) step
254 LED Frequency (step +126) step
255 Selected LED Frequency step
9 7 9 Colour functions
Factory display menu setting: Colour mixing mode-CMY, Dimmer
Curve-Square Law, Tungsten effect simulation-Off, Chromatic white-
Off, Light output stability-Off, Uniformity-Off
0 No function (0=default) step
