DMX protocol
1 2 3
Mode/channel
DMX
Value
Function
Type of
control
To activate following functions, stop in DMX value for at least 3 seconds.
Corresponding menu items are temporarily overriden
1-39
Reserved
40-44 Colour mixing mode: CMY (DMX Mode 1 and 2 only) step
45-49
Colour mixing mode: RGB (DMX mode 1 and 2), RGBAL (DMX mode 3 only)
step
50-54 Dimmer curve: Square law step
55-59 Dimmer curve: Linear step
60-79 Raw DMX proportional
Tungsten effect simulation for whites 2700K-4200K only:
80-84 Tungsten effect simulation (750W/80V): On step
85-89 Tungsten effect simulation (1000W/240V): On step
90-94 Tungsten effect simulation (1200W/240V): On step
95-99 Tungsten effect simulation (2000W/230V): On step
100-104 Tungsten effect simulation (2500W/230V): On step
105-109 Tungsten effect simulation: Off step
110-114
Save user colour (see user manual, chapter 5.1 Colour influencing functions)
step
115-119 Chromatic white: On step
120-124 Chromatic white: Off step
125-129 Light output stability On step
130-134 Light output stability Off step
135-139 Uniformity On step
140-144 Uniformity Off step
145-255 Reserved
10 8 10
0-255 CRI selection from Standard (80) to High (90+) (0=default) proportional
11 * 11
0 No function (0=default) step
1-2
Filter 4 (Medium Bastard Amber)
step
3-4
Filter 10 (Medium Yellow)
step
5-6
Filter 19 (Fire)
step
7-8
Filter 26 (Bright Red)
step
9-10
Filter 58 (Lavender)
step
11-12
Filter 68 (Sky Blue)
step
13-14
Filter 71 (Tokyo Blue)
step
15-16
Filter 79 (Just Blue)
step
17-18
Filter 88 (Lime Green)
step
19-20
Filter 90 (Dark Yellow Green)
step
21-22
Filter 100 (Spring Yellow)
step
23-24
Filter 101 (Yellow)
step
25-26
Filter 102 (Light Amber)
step
27-28
Filter 103 (Straw)
step
29-30
Filter 104 (Deep Amber)
step
31-32
Filter 105 (Orange)
step
33-34
Filter 106 (Primary Red)
step
35-36
Filter 111 (Dark Pink)
step
37-38
Filter 115 (Peacock Blue)
step
39-40
Filter 116 (Medium Blue-Green)
step
41-42
Filter 117 (Steel Blue)
step
