DMX protocol
1 2 3
Mode/channel
DMX
Value
Function
Type of
control
220-221 User colour 3 step
222-223 User colour 4 step
224-225 User colour 5 step
226-227 User colour 6 step
228-229 User colour 7 step
230-231 User colour 8 step
232-233 User colour 9 step
234-235 User colour 10 step
236-245 Rainbow effect (with fade time) from slow-> fast proportional
246-255 Rainbow effect (without fade time) from slow-> fast proportional
12 9 * Cyan/Red (8 bit)
0 - 255
Colour saturation control - coarse 0-100% (0=default for CMY
mode, 255=default for RGB mode)
proportional
13 * * Cyan/Red (16 bit)
0 - 255
Colour saturation control - fine (0=default for CMY mode,
255=default for RGB mode)
proportional
14 10 * Magenta/Green (8 bit)
0 - 255
Colour saturation control - coarse 0-100% (0=default for CMY
mode, 255=default for RGB mode)
proportional
15 * * Magenta/Green (16 bit)
0 - 255
Colour saturation control - fine (0=default for CMY mode,
255=default for RGB mode)
proportional
16 11 * Yellow/Blue (8 bit)
0 - 255
Colour saturation control - coarse 0-100% (0=default for CMY
mode, 255=default for RGB mode)
proportional
17 * * Yellow/Blue (16 bit)
0 - 255
Colour saturation control - fine (0=default for CMY mode,
255=default for RGB mode)
proportional
* * 12 Red (8 bit)
0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional
* * 13 Red (16bit)
0 - 255 Colour saturation control - fine (255=default) proportional
* * 14 Green (8 bit)
0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional
* * 15 Green (16bit)
0 - 255 Colour saturation control - fine (255=default) proportional
* * 16 Blue (8 bit)
0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional
* * 17 Blue (16bit)
0 - 255 Colour saturation control - fine (255=default) proportional
* * 18 Amber (8 bit)
0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional
* * 19 Amber (16bit)
0 - 255 Colour saturation control - fine (255=default) proportional
* * 20 Light green (8 bit)
0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional
* * 21 Light green (16bit)
0 - 255 colour saturation control - fine (255=default) proportional
18 12 22 Colour temperature correction (CTC)
