Robe ROBIN T1 PC - Frost, Zoom, Shutter;Strobe Control

DMX protocol
1 2 3
Mode/channel
DMX
Value
Function
Type of
control
0-1 8000 K step
2-64 Colour temperature changing 7978 K ->6622 K (22 K /1 DMX) proportional
65 6600 K step
66-109 Colour temperature changing 657 8K ->5622 K (22 K/1 DMX) proportional
110 5600 K (110=default) step
111-179 Colour temperature changing 5580 K ->4220 K (20 K/1 DMX) proportional
180 4200 K step
181-229 Colour temperature changing 4180 K ->3220 K (20 K/1 DMX) proportional
230 3200 K step
231-254 Colour temperature changing 3180 K ->2720 K (20K /1 DMX) proportional
255 2700K step
19 * 23 Green correction
0 Uncorrected white step
1-127 Minus green --> uncorrected white proportional
128 Uncorrected white (128=default) step
129-254 Uncorrected white --> Plus green proportional
255 Uncorrected white step
20 * 24
Colour mix control
Defines relation between Virtual Colour wheel and colour channels
"Virtual" = Virtual Colour Wheel
"Colour mix" = Colour channels (CMY/RGBALight Green/CTC)
0-9
"Virtual " has priority over "Colour mix" (0=default)
10-19 Maximum mode (highest values have priority) step
20-29 Minimum mode (lowest values have priority) step
30-39 Multiply mode (multiply "Virtual" and "Colour mix") step
40-49 Addition mode ("Virtual" + "Colour mix") step
50-59 Subtraction mode ("Virtual" – "Colour mix") step
60-69 Inverted Subtraction mode ("Colour mix"-"Virtual") step
70-79
White Point Off (CTC+Green Cor.+Virtual Colour Wheel deactivated)
step
80-128 Reserved
129 Crossfade "Virtual" only step
130-254 Crossfade between "Virtual" and "Colour mix" proportional
255 Crossfade "Colour mix" only step
21 * 25
Barndoors/Zoom/Frost time
0 Function is off (0=default) step
1 - 255
Time of barndoors, zoom and frost movement (0.1 sec-->25.5 sec.)
proportional
22 13 26
Scrim positioning
0 No function (0=default) step
1-255 Scrim inserting (0.5%-->100%) proportional
23 14 27
Scrim indexing
0-255 Scrim indexing 0°-360° /1.4°per 1 DMX/, ( 128=default)
(0 DMX=0°, 64DMX=90°, 128DMX=180°, 192DMX=270°, 255DMX=360°) proportional
24 15 28
Frost
0 Open (0=default) step
Light Frost
1-50 Light Frost from 0% to 100% proportional
51-53 100% Light Frost step
54-63 Pulse closing from slow to fast proportional
Page 7
