DMX protocol
1 2 3
Mode/channel
DMX
Value
Function
Type of
control
64-73 Pulse opening from fast to slow proportional
74-83 Ramping from fast to slow proportional
84-86 Open step
Medium Frost
87-136 Medium Frost from 0% to 100% proportional
137-139 100% Medium Frost step
140-149 Pulse closing from slow to fast proportional
150-159 Pulse opening from fast to slow proportional
160-169 Ramping from fast to slow proportional
170-172 Open step
Combined Frost
173-222 Medium Frost from 0% to 100% (Light Frost inserted) proportional
223-225 100% Medium Frost (Light Frost inserted) step
226-235 Pulse closing from slow to fast proportional
236-245 Pulse opening from fast to slow proportional
246-255 Ramping from fast to slow proportional
25 16 29
0 - 255 Zoom from max. to min. beam angle (128=default) proportional
26 * 30
0-255 Fine zooming (0=default) proportional
27 17 31
0-255 Fine correction of the colour of the image edge (128=default) proportional
28 18 32 Barndoors rotation
0-255 Rotation 0°--> 180° (128=default) proportional
29 19 33
0-255 Movement from Outward to Inward (0=default) proportional
30 20 34
0-255 Movement from Outward to Inward (0=default) proportional
31 21 35
0-255 Movement from Outward to Inward (0=default) proportional
32 22 36
0-255 Movement from Outward to Inward (0=default) proportional
33 23 37
0 - 31 Shutter closed step
32 - 63 Shutter open (32=default) step
64 - 95 Strobe-effect from slow to fast proportional
96 - 127 Shutter open step
128 - 143 Opening pulse in sequences from slow to fast proportional
144 - 159 Closing pulse in sequences from fast to slow proportional
160 - 191 Shutter open step
192 - 223 Random strobe-effect from slow to fast proportional
224 - 255 Shutter open step
34 24 38
0 - 255 Dimmer intensity from 0% to 100% (0=default) proportional
35 * 39
0 - 255 Fine dimming (0=default) proportional
